A79618-001

Headers, Male Pins Overview

The Omnetics A79618-001 is a Polarized Nano series connector header featuring 10 positions in a dual-row configuration. Designed for surface mount right-angle installation, it utilizes a 0.025-inch (0.64mm) mating pitch with a 0.040-inch (1.02mm) row spacing. The contacts are constructed from beryllium copper and copper alloy, finished with 50.0µin gold plating on the mating interface and tin-lead on the tail. Rated for 1A per contact, it operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Polarized male/female design ensures correct mating alignment
• Surface mount right-angle termination for PCB integration
• Gold-plated contacts provide reliable signal transmission
• Push-pull locking mechanism secures connection

Headers, Male Pins Applications

• Board-to-board interconnects requiring polarized alignment
• High-density electronic assemblies
• Precision instrumentation modules
• Neuroscience research equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official datasheet to confirm pin count, polarization type, and termination style. Ensure compatibility with mating connectors in the Polarized Nano series. Confirm that the surface mount footprint matches the target PCB layout specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a polarized, right-angle surface mount header is required for high-density applications. The dual-row layout supports 10 positions with precise alignment features. Consider the thermal rating and current capacity relative to the system's electrical requirements and environmental operating conditions.

Headers, Male Pins Part Context

This part belongs to the Polarized Nano (PZN) series by Omnetics, designed for precision interconnects. It complements the broader Nano Strip family, offering specialized polarization features for secure board-to-board connections in compact form factors suitable for advanced electronic systems.
