A79619-001

$65.29

Description：NANO 10POS MALE/FEMALE POLARIZED
Series：Polarized Nano
Mfr：Omnetics
Package：Bag

SKU:18fbdff0b9be Category: Headers, Male Pins Brand: Omnetics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

A79619-001 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Omnetics. Its product description is NANO 10POS MALE/FEMALE POLARIZED. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A79619-001

Description：NANO 10POS MALE/FEMALE POLARIZED
Series：Polarized Nano
Mfr：Omnetics
Package：Bag
Connector Type：Header
Contact Type：Female Socket; Male Pin
Pitch - Mating：0.025" (0.64mm)
Number of Positions：10
Number of Rows：2
Row Spacing - Mating：0.040" (1.02mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：-
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.060" (1.52mm)
Contact Length - Post：0.100" (2.54mm)
Overall Contact Length：-
Insulation Height：0.170" (4.32mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：50.0µin (1.27µm)
Contact Finish - Post：Tin-Lead
Contact Material：Beryllium Copper
Insulation Material：Thermoplastic
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Natural
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for A79619-001

A79619-001

Headers, Male Pins Overview

The Omnetics A79619-001 is a Polarized Nano (PZN) series connector header designed for through-hole straight termination. It features 10 positions arranged in a single row with a 0.025-inch (0.64mm) contact spacing. The component utilizes mixed gender contacts, incorporating both male pins and female sockets within the same housing to facilitate polarized mating. Contact surfaces are gold-plated with a thickness of 50.0µin (1.27µm), while the posts feature tin-lead plating. Constructed from thermoplastic insulation, it supports a wide operating temperature range of -55°C to 125°C and provides a rated current of 1A per contact.

Headers, Male Pins Feature Summary

Polarized design ensures correct orientation during mating
Mixed gender contact configuration combines male pins and female sockets
Through-hole straight termination for reliable PCB mounting

Headers, Male Pins Applications

Precision interconnects in neuroscience research equipment
Compact electronic systems requiring space-constrained solutions
High-reliability defense electronics applications

Headers, Male Pins Procurement Notes

Verify that the specific requirement for mixed gender contacts aligns with the system design, as this part integrates both male and female terminals. Confirm through-hole straight mounting compatibility with the target PCB layout. Ensure environmental conditions remain within the specified -55°C to 125°C operational range for optimal performance.

Headers, Male Pins Selection Notes

Select this component when a polarized connection is required to prevent misalignment. The mixed gender contact arrangement simplifies assembly by eliminating the need for separate male and female headers. Choose this model over standard Nano Strip variants specifically when polarization is critical for the application's reliability.

Headers, Male Pins Part Context

This part belongs to the Polarized Nano (PZN) series by Omnetics, distinct from the standard Nano Strip line. The PZN series emphasizes secure alignment through polarization mechanisms. It serves specialized markets demanding high precision and reliability in miniature form factors, particularly where standard connectors might risk incorrect mating.
