A79624-001

Headers, Male Pins Overview

The Omnetics A79624-001 is a Polarized Nano (PZN) series connector header featuring 12 positions in a single row. It utilizes a 0.025-inch (0.64mm) pitch with a 0.040-inch (1.02mm) row spacing. Designed for surface mount installation, the connector supports through-hole termination methods and employs a push-pull locking mechanism. The contacts are gold-plated with a thickness of 50.0µin (1.27µm), ensuring reliable signal transmission. Rated for 1A per contact, it operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Features a polarized design to prevent misalignment during mating.
• Utilizes a push-pull locking system for secure connection retention.
• Supports surface mount technology for automated assembly processes.

Headers, Male Pins Applications

• Neuroscience research instrumentation
• Precision medical devices
• High-density electronic interconnects

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Omnetics datasheet to ensure compatibility with required termination styles and housing configurations. Confirm that the selected variant matches the intended board layout and mating connector specifications. Cross-reference the part number with the manufacturer's current product status to confirm availability and obsolescence warnings before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when high-density interconnects with precise alignment are required. The polarized nano series offers robust mechanical stability for sensitive applications. Ensure the chosen variant supports the necessary current rating and environmental conditions. Verify that the surface mount footprint aligns with the PCB design constraints and manufacturing capabilities.

Headers, Male Pins Part Context

This component belongs to the Polarized Nano (PZN) series by Omnetics, designed for precision applications. The series is known for its compact form factor and reliable performance in demanding environments. It serves as a critical interconnect solution for specialized industries requiring high-density connections with strict alignment requirements.

Headers, Male Pins Replacement Considerations

Consult the official Omnetics cross-reference guide for verified substitute part numbers. Ensure any replacement maintains identical pin count, pitch, and polarization features. Verify compatibility with existing mating connectors and mounting configurations before implementation.

Headers, Male Pins FAQ

What is the contact material composition?

The contacts are made from platinum-copper alloy or copper alloy, providing durability and conductivity.

Does the connector support automated assembly?

Yes, the surface mount design facilitates integration into automated pick-and-place manufacturing processes.
