A79632-001

Headers, Receptacles, Female Sockets Overview

The Omnetics A79632-001 is a Polarized Nano (PZN) series connector featuring 16 contacts in a single row. It utilizes vertical surface mount termination for board-to-board applications. The connector supports male and female polarized mating with a 0.025-inch pitch. Gold-plated contacts ensure reliable signal transmission, while the thermoplastic insulator provides structural integrity.

Headers, Receptacles, Female Sockets Feature Summary

• Vertical surface mount termination design
• Polarized nano strip configuration
• Single row contact arrangement

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnects
• Precision instrumentation systems
• Neuroscience research equipment

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific datasheet revision and RoHS compliance status directly with Omnetics Connector Corp before procurement. Confirm that the vertical surface mount footprint matches your PCB layout requirements. Ensure the polarized keying mechanism aligns with your assembly orientation needs to prevent mating errors during production integration.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a compact, high-density vertical interconnect is required. The single-row format suits space-constrained designs needing 16 positions. Verify that the vertical profile fits within your system height constraints. Consider the polarized feature if misalignment prevention is critical for your specific application environment.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Polarized Nano series, known for high-reliability miniature connectors. It complements other PZN variants like the A79623-001 but differs in contact count and termination style. The series targets demanding applications requiring precise alignment and small form factors in electronic assemblies.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other PZN series parts with matching 16-pin counts and vertical termination, such as A79632-002 variants. Verify pinout compatibility and mechanical dimensions before swapping. Cross-reference with Omnetics official substitution guides for equivalent performance specifications.
