A79639-001

Headers, Receptacles, Female Sockets Overview

The A79639-001 is a Polarized Nano (PZN) series connector header manufactured by Omnetics. It features 18 positions in a single row with a 0.025-inch (0.64mm) mating pitch and 0.040-inch (1.02mm) row spacing. Designed for through-hole straight termination, this male pin connector utilizes gold-plated contacts with a 50.0µin thickness on the mating interface. The housing is made of natural thermoplastic insulation, supporting a rated current of 1A per contact across an operating temperature range of -55°C to 125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Polarized design ensures correct orientation during board-to-board mating
• Micro-miniature form factor optimized for high-density applications
• Gold-plated circular contacts provide reliable signal transmission
• Through-hole straight termination secures connection to printed circuit boards

Headers, Receptacles, Female Sockets Applications

• High-density board-to-board interconnects
• Precision connectors for neuroscience research equipment
• Rugged micro-miniature electronic assemblies
• Space-constrained digital signal processing modules

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Omnetics documentation to confirm pin count, row configuration, and termination style. Ensure compatibility with mating receptacles within the Polarized Nano series. Cross-reference datasheets for mechanical dimensions and electrical ratings prior to integration into final designs.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a single-row, 18-position male header is required for through-hole mounting. Consider the 0.025-inch pitch for density requirements and verify that the polarized feature aligns with assembly orientation needs. Confirm thermal and current ratings match system specifications.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Polarized Nano (PZN) series, which focuses on precision connectivity for demanding environments. Omnetics designs these connectors to support rigorous performance standards in miniature formats, often utilized in specialized scientific and industrial instrumentation where reliability is critical.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Omnetics substitution guides for verified equivalents. Generic rectangular headers may lack the specific polarization and micro-pitch tolerances required for proper mating with existing PZN series receptacles.

Headers, Receptacles, Female Sockets FAQ

What is the contact material used in the A79639-001?

The contacts are made from copper alloy with a gold plating finish on the mating interface.

Does this connector support surface mount installation?

No, the A79639-001 is designed specifically for through-hole straight termination.
