A8086CH

Overview

The Hoffman Enclosures Inc. A8086CH is a wall-mount metal enclosure constructed from mild steel with a polyester powder-coated finish in ANSI 61 Gray. It features dimensions of 8 inches by 8 inches by 6 inches (203 mm x 203 mm x 152 mm). The unit includes a single door secured with screw-down clamps and utilizes a continuous hinge design for durability. It carries IP65, NEMA 12, and NEMA 13 ratings, ensuring protection against dust, water jets, and falling dirt.

Feature Summary

• Continuous hinge door design for enhanced structural integrity
• Screw-down clamp locking mechanism for secure closure
• Polyester powder-coated mild steel construction
• IP65 and NEMA 12/13 environmental protection ratings

Applications

• Industrial control panel housing
• Electrical junction box installation
• Wall-mounted equipment protection
• Outdoor or harsh environment electronics enclosure

Procurement Notes

Verify the exact dimensional requirements against the 8x8x6 inch specification before procurement. Confirm that the mild steel material and ANSI 61 Gray finish meet your facility's aesthetic and corrosion resistance standards. Ensure the IP65/NEMA 12/13 rating aligns with the specific environmental hazards present at the installation site. Check for any required accessories such as mounting hardware or internal rails not included in the base unit.

Selection Notes

Select this model when a compact, durable enclosure is needed for wall mounting in environments requiring protection against dust and water jets. The continuous hinge offers superior longevity compared to standard hinges. Consider the mild steel construction if cost-effectiveness is prioritized over stainless steel alternatives, while noting the polyester coating provides necessary surface protection.

Part Context

This component belongs to the Hoffman Enclosures line of industrial metal boxes. It is designed for general-purpose electrical and electronic housing applications. The product series emphasizes robust construction and standardized sizing to facilitate easy integration into various industrial setups and control systems.

Replacement Considerations

Direct substitutes may include other NEMA 12 enclosures with identical 8x8x6 dimensions. Verify compatibility of mounting hole patterns and door swing clearance when replacing existing units. Ensure the replacement maintains the same IP65 rating for equivalent environmental protection levels.
