AA-24.000MAHE-T

Crystals Overview

The AA-24.000MAHE-T is a surface-mount quartz crystal manufactured by TXC Corporation, designed for automotive applications compliant with AEC-Q200 standards. It operates at a fundamental frequency of 24 MHz with a load capacitance of 12 pF. The component exhibits a frequency tolerance and stability of ±30 ppm. It features a two-pin SMD package with an equivalent series resistance of 50 Ohms.

Crystals Feature Summary

• Automotive-grade reliability certified to AEC-Q200 standards
• Fundamental mode quartz crystal operation
• Surface-mount design for automated assembly

Crystals Applications

• Automotive electronic systems
• AEC-Q200 qualified circuit designs
• 24 MHz clock generation in vehicles

Crystals Procurement Notes

Verify the specific suffix HE-T against official TXC documentation to confirm the exact load capacitance and stability specifications. Ensure the procurement channel provides valid traceability for AEC-Q200 certification requirements. Cross-reference the datasheet revision date to guarantee compliance with current automotive quality standards.

Crystals Selection Notes

Select this component when an automotive-certified 24 MHz fundamental crystal is required. The 12 pF load capacitance must match the oscillator circuit design. Verify that the ±30 ppm stability meets the system timing requirements. Confirm the SMD package dimensions fit the PCB layout constraints.

Crystals Part Context

This part belongs to the AA series of automotive crystals from TXC Corporation. These components are engineered for high reliability in harsh environments. The series supports various frequencies and packaging options tailored for automotive electronics manufacturing.

Crystals Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
