Product Detailed Parameters
- Description：RF FILTER BAND PASS 2.619GHZ MOD
- Series：-
- Mfr：Anatech Electronics Inc.
- Package：Box
- Frequency：2.619GHz Center
- Bandwidth：10MHz
- Filter Type：Band Pass
- Ripple：0.6dB
- Insertion Loss：3dB
- Mounting Type：Chassis Mount
- Package / Case：Module, SMA Connectors
- Size / Dimension：4.690" L x 3.190" W (119.13mm x 81.03mm)
- Height (Max)：1.180" (29.97mm)
Download product information
Overview
The AB2619B1221 is a cavity bandpass RF filter manufactured by Anatech Electronics Inc. It operates with a center frequency of 2.619 GHz and provides a bandwidth of 10 MHz. The component features an insertion loss of 3 dB and a ripple of 0.6 dB. It utilizes SMA connectors for interface connections and is designed for chassis mounting. The physical dimensions include a maximum height of 1.180 inches (29.97 mm). This module is RoHS compliant and classified under ECCN EAR99.
Feature Summary
- Cavity construction for stable RF filtering performance
- SMA connector interface for standard integration
- Chassis mount design for secure installation
Applications
- Military radio frequency systems
- Commercial RF communication equipment
- Test and measurement instrumentation
Procurement Notes
Verify the specific datasheet version to confirm mechanical tolerances and connector specifications. Ensure compatibility with existing chassis mounting hardware. Confirm RoHS compliance status if required by project regulations. Check for any specific handling instructions related to cavity filter sensitivity.
Selection Notes
Select this component when a fixed 2.619 GHz center frequency with 10 MHz bandwidth is required. Consider the 3 dB insertion loss and 0.6 dB ripple specifications against system link budget requirements. Verify that chassis mounting is feasible within the enclosure design. Ensure SMA connectors match the system interconnect strategy.
Part Context
Anatech Electronics Inc. specializes in standard and custom RF filters for military and commercial applications. The AB series typically denotes cavity bandpass filters. This model fits within their portfolio of precision microwave components designed for high-reliability environments requiring stable frequency response.
Replacement Considerations
No public confirmed substitute part numbers are available for direct replacement. Cross-reference with other Anatech models only if frequency and bandwidth parameters can be adjusted within system tolerances.
