Product Detailed Parameters
- Description：RF FILTER BANDPASS 5.8GHZ MODULE
- Series：-
- Mfr：Anatech Electronics Inc.
- Package：Box
- Frequency：5.8GHz Center
- Bandwidth：200MHz
- Filter Type：Band Pass
- Ripple：0.2dB
- Insertion Loss：0.5dB
- Mounting Type：Chassis Mount
- Package / Case：Module
- Size / Dimension：4.000" L x 3.449" W (101.60mm x 87.60mm)
- Height (Max)：1.260" (32.00mm)
Download product information
Overview
The AB5800B1249 is a cavity band pass RF filter manufactured by Anatech Electronics Inc. It operates with a center frequency of 5.8GHz and provides a bandwidth of 200MHz, covering the 5700-5900 MHz range. The component features an insertion loss of 0.5dB within its passband. Designed for radio frequency applications, this module delivers precise frequency selection capabilities suitable for systems requiring stable signal filtering in the microwave spectrum.
Feature Summary
- Cavity construction for high-performance RF filtering
- Precise center frequency tuning at 5.8GHz
- Defined 200MHz operational bandwidth
Applications
- Radio frequency signal processing
- Microwave communication systems
- RF filter modules requiring specific bandpass characteristics
Procurement Notes
Verify the exact datasheet specifications against current manufacturer documentation before integration. Confirm that the 5.8GHz center frequency and 200MHz bandwidth align with system requirements. Ensure compatibility with existing RF infrastructure regarding impedance and connector types. Check for any recent revisions to the part number or manufacturing standards that may affect performance metrics or physical dimensions.
Selection Notes
Select this component when a fixed 5.8GHz center frequency with a 200MHz bandwidth is required. Consider the 0.5dB insertion loss specification for signal integrity needs. Evaluate the cavity design benefits for stability compared to other filter technologies. Ensure the application environment supports the operational parameters defined for this specific RF module.
Part Context
Anatech Electronics Inc. specializes in the design and manufacturing of standard and custom RF filters and microfilters for military and commercial sectors. The company focuses on providing precise frequency control solutions. This model represents their capability in producing cavity-based bandpass filters for specialized radio frequency applications.
Replacement Considerations
No public confirmed substitute part numbers are available for this specific model. Custom designs may be requested if exact matches are unavailable. Verify electrical specifications carefully when considering alternative components from other manufacturers.
