AB915B528

$401.20

Description：RF FILTER BAND PASS 95MHZ MODULE
Series：-
Mfr：Anatech Electronics Inc.
Package：Box

SKU:0e3350984c78 Category: RF Filters Brand: Anatech Electronics Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILTER BAND PASS 95MHZ MODULE
Series：-
Mfr：Anatech Electronics Inc.
Package：Box
Frequency：95MHz Center
Bandwidth：10MHz
Filter Type：Band Pass
Ripple：-
Insertion Loss：1.5dB
Mounting Type：Chassis Mount
Package / Case：Module, SMA Connectors
Size / Dimension：4.720" L x 2.360" W (119.89mm x 59.94mm)
Height (Max)：1.890" (48.01mm)

Download product information

AB915B528

Overview

The AB915B528 is a cavity bandpass RF filter manufactured by Anatech Electronics Inc. It features a center frequency of 95MHz and a bandwidth of 10MHz. The insertion loss is specified at 1.5dB. The component utilizes SMA connectors for interface connections. Physical dimensions are 4.720 inches in length, 2.360 inches in width, and 1.890 inches in height (119.89mm x 59.94mm x 48.01mm). The unit is designed for chassis mounting.

Feature Summary

Cavity construction for stable RF performance
Bandpass filtering capability centered at 95MHz
SMA connector interfaces for signal transmission

Applications

Radio frequency signal processing systems
Microwave communication equipment
Test and measurement instrumentation

Procurement Notes

Verify the specific datasheet version for the AB915B528 to confirm exact electrical tolerances and mechanical drawings before integration. Ensure that the SMA connector polarity and mating requirements align with the system design. Confirm chassis mounting hole patterns match the enclosure specifications. Check for any environmental ratings if outdoor or harsh condition deployment is planned.

Selection Notes

Select this component when a fixed 95MHz center frequency with 10MHz bandwidth is required. The 1.5dB insertion loss specification should be evaluated against system link budget constraints. The chassis mount form factor dictates the mechanical integration approach within the host equipment. Verify that the physical footprint fits within the available space in the assembly.

Part Context

Anatech Electronics Inc. specializes in the design and manufacturing of radio frequency and microwave filters. The company produces both standard and custom components for military and commercial applications. This part belongs to their line of cavity bandpass filters, which are engineered for high performance in RF environments.

Replacement Considerations

No public confirmed substitute part numbers are identified for the AB915B528. Custom designs may be requested from the manufacturer if exact matches are unavailable.
