ABM11AAIG-32.000MHZ-9-2Z-T3

Crystals Overview

The ABM11AAIG-32.000MHZ-9-2Z-T3 is a surface-mount quartz crystal manufactured by Abracon LLC, designed for automotive and industrial applications. It operates at a fundamental frequency of 32 MHz with a load capacitance of 9 pF. The component meets AEC-Q200 qualification standards, ensuring reliability in harsh environments. Key electrical parameters include a frequency tolerance of ±15 ppm and a frequency stability of ±50 ppm over the operating temperature range of -40°C to +125°C. The equivalent series resistance (ESR) is specified at 100 Ohms. The device utilizes a 2-SMD, no-lead package with dimensions of 2.0 mm x 1.6 mm and a maximum height of 0.8 mm.

Crystals Feature Summary

• AEC-Q200 qualified for automotive grade reliability
• Ultra-miniature 2-SMD surface mount footprint
• Wide operating temperature range suitable for harsh environments

Crystals Applications

• Automotive electronic control units
• Infotainment systems
• Telematics modules
• Industrial sensor interfaces

Crystals Procurement Notes

Verify the specific suffix codes against the official Abracon datasheet to ensure exact matching of load capacitance, tolerance, and packaging configuration. Confirm that the procurement source provides valid traceability documentation required for AEC-Q200 components. Ensure the receiving facility adheres to standard handling procedures for sensitive surface-mount devices to prevent physical damage during installation.

Crystals Selection Notes

Select this component when an automotive-grade crystal is required for 32 MHz clocking applications within tight space constraints. The 9 pF load capacitance must match the oscillator circuit design specifications. Consider the ±15 ppm tolerance and ±50 ppm stability limits relative to system timing requirements. The wide temperature range makes it suitable for under-hood or exterior automotive electronics where thermal extremes are common.

Crystals Part Context

This part belongs to the ABM11AAIG series of ultra-miniature crystals from Abracon. The series is characterized by its small form factor and robust construction for automotive use. It differs from other ABM11 variants primarily through its specific frequency, load capacitance, and tolerance ratings. The 'AAIG' designation indicates the automotive grade and specific package style within the broader product line.

Crystals Replacement Considerations

Direct substitutes must match the 32 MHz frequency, 9 pF load capacitance, 2-SMD package, and AEC-Q200 qualification. Verify that alternative parts maintain the same ±15 ppm tolerance and -40°C to +125°C temperature range. Cross-reference with Abracon's official substitution guide for confirmed compatible replacements.
