ABR3407I8-0100S

Antennas RF Overview

The ABR3407I8-0100S is a linear PCB antenna manufactured by Abracon LLC, designed for RF applications. It operates within the frequency range of 868MHz to 870MHz and provides a gain of 1.28dBi. The component features an IPEX MHF1 (U.FL) termination interface and maintains a standard impedance of 50 Ohms. Physical dimensions include a length of 34 mm and a height of 0.8 mm. It supports a maximum operating temperature of +85 C. This antenna is intended for use in ISM, LoRa, LPWAN, and Sigfox applications.

Antennas RF Feature Summary

• Linear PCB antenna design optimized for specific ISM band operations
• Integrated IPEX MHF1 (U.FL) connector for direct RF module attachment
• Compact form factor suitable for space-constrained embedded devices

Antennas RF Applications

• ISM band communication systems
• LoRa network modules
• LPWAN device integration
• Sigfox compatible terminals

Antennas RF Procurement Notes

Verify current product status carefully as multiple sources indicate this model may be obsolete or no longer manufactured. Confirm availability with authorized distributors before finalizing procurement plans. Ensure compatibility with existing U.FL interfaces on target hardware. Request updated datasheets from official channels to verify technical specifications against legacy documentation.

Antennas RF Selection Notes

Select this component only if the application requires operation specifically within the 868MHz to 870MHz range. Verify that the IPEX MHF1 connector type matches the RF module interface. Consider the physical constraints of the 34mm length and 0.8mm height during PCB layout. Evaluate thermal requirements against the +85 C maximum operating temperature limit.

Antennas RF Part Context

This part belongs to Abracon's portfolio of RF antennas and connectivity solutions. It is categorized under RF Antennas, specifically linear PCB types. The product line focuses on providing integrated antenna solutions for wireless communication modules, supporting various industrial and consumer IoT standards.

Antennas RF Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Due to reported obsolescence, consult manufacturer resources for potential end-of-life alternatives or newer series replacements.
