ABS1410519

ABS1410519 is listed in the Limit Switches range at ChipApex. The manufacturer field lists Panasonic Electric Works. Its product description is SWITCH SNAP ACT SPDT 0.1A 125V. Review the specifications below when checking this part for your BOM.

Limit Switches specifications for ABS1410519

• Description：SWITCH SNAP ACT SPDT 0.1A 125V
• Series：ABS
• Mfr：Panasonic Electric Works
• Package：Bulk
• Circuit：SPDT
• Switch Function：On-Mom
• Current Rating (Amps)：100mA (AC/DC)
• Voltage Rating - AC：125 V
• Actuator Type：Round (Pin Plunger)
• Mounting Type：Chassis Mount
• Termination Style：Solder Lug
• Ingress Protection：IP50 - Dust Protected
• Features：-
• Operating Force：150gf
• Release Force：20gf
• Operating Position：0.330" (8.4mm)
• Pretravel：0.024" (0.6mm)
• Differential Travel：0.004" (0.1mm)
• Overtravel：0.015" (0.4mm)
• Operating Temperature：-40°C ~ 85°C
• Voltage Rating - DC：30 V

Limit Switches datasheet and documents for ABS1410519
