ABSNS6A7-368M02CM

Overview

The ABSNS6A7-368M02CM is a surface-mount bandpass SAW filter manufactured by Abracon LLC. It operates at a center frequency of 1880 MHz with a bandwidth of 60 MHz. The device features an insertion loss of 3 dB and is designed for a 50 Ohm impedance system. It supports a voltage rating of 5 V and utilizes SMD/SMT termination styles. The physical package dimensions are 3.0 x 3.0 x 1.3 mm, ensuring compatibility with compact wireless infrastructure layouts.

Feature Summary

• Surface-mount SAW technology for wireless infrastructure
• Bandpass filtering centered at 1880 MHz
• Compact 3.0 x 3.0 mm footprint

Applications

• Wireless base station systems
• Infrastructure signal processing
• RF front-end modules

Procurement Notes

Verify the complete part number ABSNS6A7-368M02CM against official Abracon documentation to ensure correct frequency and bandwidth specifications. Confirm RoHS compliance status if required for specific regulatory environments. Check current manufacturer lead times as they may vary. Ensure the receiving facility handles ESD-sensitive components appropriately during installation.

Selection Notes

Select this component when a 60 MHz bandwidth at 1880 MHz is required for base station applications. The 3 dB insertion loss and 50 Ohm impedance match standard RF interface requirements. The small 3.0 x 3.0 mm package suits space-constrained designs. Verify that the 5 V voltage rating meets the circuit's operational limits before integration.

Part Context

This component belongs to the Abracon ABSNS6A7 series of SMD SAW filters. The series offers various center frequencies including 836.5 MHz and 881.5 MHz, alongside the 1880 MHz variant. These filters are engineered specifically for robust performance in demanding wireless infrastructure environments, providing reliable signal selection.

Replacement Considerations

Cross-reference with other ABSNS6A7 variants such as ABSNS6A7-1CHM011M for different frequency bands. Ensure any substitute maintains the 60 MHz bandwidth and 1880 MHz center frequency. Verify package compatibility and electrical parameters like insertion loss and impedance.
