ACB2012L-030-T

Overview

The ACB2012L-030-T is a ferrite chip bead from the TDK ACB series, designed for effective electromagnetic interference (EMI) suppression in signal lines. It features a single-line configuration with an impedance of 30 ohms and a rated current of 500 mA. The component utilizes a compact 0805 (2012 metric) surface-mount package, facilitating simple in-series implementation for circuit protection.

Feature Summary

• Provides effective EMI suppression in signal lines
• Designed for simple in-series implementation
• Compact 0805 surface-mount footprint

Applications

• Signal line noise suppression
• Electromagnetic interference filtering

Procurement Notes

Verify the specific impedance value and current rating against the official manufacturer datasheet prior to integration. Confirm that the 0805 package dimensions align with the target PCB layout constraints. Ensure the selected component meets the required thermal and electrical specifications for the intended application environment.

Selection Notes

Select this component when a low-profile solution is required for high-frequency noise attenuation on data or control lines. The 30-ohm impedance characteristic targets specific frequency ranges; verify spectral requirements against the datasheet curve. The 500 mA rating must accommodate peak operational currents without saturation.

Part Context

This part belongs to the TDK ACB series of ferrite beads, which are engineered for general-purpose EMC suppression. The series offers various impedance values within a standardized 0805 package, allowing designers to maintain consistent board layouts while adjusting filtering characteristics for different signal integrity needs.

Replacement Considerations

Consult the official TDK documentation for verified alternative part numbers. Substitutions must match the 0805 package, 30-ohm impedance, and 500 mA current rating to ensure functional compatibility.
