ACG0806U

Antennas RF Overview

The ACG0806U is a surface-mount ultra-wideband (UWB) chip antenna manufactured by Abracon LLC. It operates within a frequency range of 3.3 GHz to 7.2 GHz, with a center frequency of 5.3 GHz and a bandwidth of 4 GHz. The component features linear polarization and a nominal impedance of 50 Ohms. Key electrical specifications include a Voltage Standing Wave Ratio (VSWR) of 3.5. The physical dimensions are 8 mm in length, 6 mm in width, and 1.2 mm in height. It supports operating temperatures from -40°C to +100°C.

Antennas RF Feature Summary

• Supports Ultra-Wideband (UWB) communication protocols for high-precision location tracking.
• Designed for compact surface-mount integration into mobile and IoT devices.
• Provides linear polarization suitable for diverse device orientations.

Antennas RF Applications

• Secure Car Access systems
• Indoor Navigation solutions
• Item Tracking and Object Detection
• Smart Access control

Antennas RF Procurement Notes

Verify the manufacturer part number against official Abracon documentation to ensure authenticity. Confirm that the received components match the specified package type and marking codes. Check for valid RoHS compliance certificates as required by project specifications. Ensure storage conditions adhere to moisture sensitivity levels defined in the datasheet to maintain performance integrity upon installation.

Antennas RF Selection Notes

Select this component when designing circuits requiring UWB functionality within the 3.3 GHz to 7.2 GHz spectrum. Consider the 50 Ohm impedance matching requirements for the RF trace layout. Evaluate the 8x6 mm footprint constraints against available PCB space. Assess thermal stability needs given the -40°C to +100°C operational range for harsh environment deployments.

Antennas RF Part Context

This component belongs to the ACG series of chip antennas from Abracon LLC. It is engineered specifically for ISM band applications, focusing on UWB technology. The design facilitates miniaturization in modern electronics where space is limited but high-frequency performance is critical for accurate ranging and data transmission.

Antennas RF Replacement Considerations

Abracon also offers the ACG0301U and ACG0502U models within the same UWB antenna family. These alternatives may provide different form factors or mounting configurations while maintaining similar UWB performance characteristics. Verify compatibility with existing board layouts before substitution.
