Product Detailed Parameters
- Description：DIODE STANDARD 200V 1A 2010
- Series：-
- Mfr：Comchip Technology
- Package：Tape & Reel (TR)
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：200 V
- Current - Average Rectified (Io)：1A
- Voltage - Forward (Vf) (Max) @ If：1 V @ 1 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：5 µA @ 200 V
- Capacitance @ Vr, F：8pF @ 4V, 1MHz
- Mounting Type：Surface Mount
- Package / Case：2-SMD, No Lead
- Supplier Device Package：2010/DO-214AC
- Operating Temperature - Junction：-65°C ~ 175°C
- Grade：Automotive
- Qualification：AEC-Q101
Download product information
Overview
The ACGRAT101-HF is a surface-mount Schottky rectifier manufactured by Comchip Technology. It features a single diode configuration in an SOD-123H-2 package. Key electrical parameters include a maximum repetitive reverse voltage (VRRM) of 200 V and a forward current (IF) of 1 A. The device exhibits a maximum forward voltage (VF) of 920 mV at rated current and a maximum reverse leakage current (IR) of 10 mA. It supports a forward surge current (IFSM) of 30 A and operates within a temperature range of -55°C to +150°C. The component holds AEC-Q101 qualification for automotive reliability.
Feature Summary
- AEC-Q101 qualified for automotive applications
- Low profile SMD/SMT construction
- High thermal stability up to 150°C
Applications
- Automotive electronics systems
- General purpose rectification
- DC-DC converter circuits
Procurement Notes
Verify the specific datasheet revision and AEC-Q101 certification status directly with Comchip Technology or authorized distributors before integration. Confirm that the SOD-123H-2 package dimensions match your PCB footprint requirements. Ensure operating conditions remain within the specified -55°C to +150°C junction temperature limits to maintain device integrity and performance standards.
Selection Notes
Select this component when a low-profile, automotive-grade Schottky rectifier is required for space-constrained designs. The 200V rating and 1A current capacity suit moderate power applications. Consider the 920mV forward voltage drop for efficiency calculations. Verify compatibility with automated assembly processes due to the SMD form factor and ensure adequate thermal management for high-temperature environments.
Part Context
This part belongs to Comchip Technology's line of surface-mount Schottky diodes designed for robust performance. The manufacturer specializes in SMD discrete semiconductors, including rectifiers and TVS diodes. Many products in this portfolio meet AEC-Q101 standards, targeting the automotive sector. The company emphasizes compact packaging solutions like the SOD-123H-2 for modern electronic assemblies.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult official cross-reference lists from Comchip Technology or authorized distributors for verified alternatives.
