Product Detailed Parameters
- Description：DIODE STANDARD 1000V 3A 2114
- Series：-
- Mfr：Comchip Technology
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：1000 V
- Current - Average Rectified (Io)：3A
- Voltage - Forward (Vf) (Max) @ If：1 V @ 3 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：5 µA @ 1000 V
- Capacitance @ Vr, F：23pF @ 4V, 1MHz
- Mounting Type：Surface Mount
- Package / Case：2-SMD, No Lead
- Supplier Device Package：2114/DO-214AA
- Operating Temperature - Junction：-65°C ~ 175°C
- Grade：Automotive
- Qualification：AEC-Q101
Download product information
Overview
The ACGRBT305-HF is a general-purpose rectifier diode manufactured by Comchip Technology. It features an average rectified current of 3 A and a repetitive peak reverse voltage (VRRM) of 1000 V. The device is housed in a surface-mount SMD/SMT package, specifically identified as the 2114 case style. It operates within a temperature range from -55°C to +150°C junction temperature. The component holds AEC-Q101 qualification for automotive applications and complies with RoHS standards.
Feature Summary
- AEC-Q101 qualified for automotive reliability requirements
- High voltage capability with 1000 V reverse voltage rating
- Surface-mount construction in compact 2114 package
Applications
- Automotive electronic circuits requiring high-voltage rectification
- General-purpose power supply rectification
- Industrial equipment power management systems
Procurement Notes
Verify the specific datasheet version and manufacturer documentation to confirm current lifecycle status, as availability information may vary between active and obsolete classifications across different distributors. Ensure the ordering part number matches the exact suffix required for your manufacturing process and packaging preferences.
Selection Notes
Select this component when a 3 A current rating and 1000 V blocking voltage are required in a surface-mount form factor. The AEC-Q101 qualification makes it suitable for automotive environments where thermal stability up to 150°C is necessary. Compare package dimensions against PCB layout constraints before finalizing the design.
Part Context
Comchip Technology specializes in discrete semiconductors including rectifiers and Schottky diodes. The ACGRBT305-HF belongs to their general-purpose rectifier lineup, designed for robust performance in standard power conversion applications. The company emphasizes RoHS compliance and automotive-grade reliability in its product portfolio.
Replacement Considerations
Consult official Comchip Technology documentation or authorized distributor databases for verified substitute part numbers. Do not assume cross-compatibility with other manufacturers' 3 A 1000 V rectifiers without verifying electrical parameters and physical footprint compatibility.
