ACMP-1566-301-T

Overview

The Abracon ACMP-1566-301-T is a surface-mount common mode choke designed for power line filtering. It features a ferrite core and supports a maximum DC current of 13A with a maximum DC resistance of 5mOhms. The component provides an impedance of 300 Ohms at 100 MHz. It operates within a temperature range of -40°C to +125°C and utilizes a two-line configuration for effective noise suppression in compact PCB layouts.

Feature Summary

• Utilizes ferrite core technology for high-frequency noise attenuation
• Supports high continuous DC current ratings for power applications
• Surface-mount design facilitates automated PCB assembly

Applications

• Power supply input filtering
• DC-DC converter output stages
• Industrial control system power lines

Procurement Notes

Verify the specific part number against official Abracon documentation to ensure compatibility with your circuit requirements. Confirm that the package dimensions and pinout match your PCB footprint exactly. Check for any recent revisions or suffix changes that may affect electrical characteristics or mechanical fit before finalizing procurement orders.

Selection Notes

Select this component when high current handling capacity is required alongside moderate common mode impedance. Ensure the operating environment stays within the specified temperature limits. Verify that the low DC resistance meets efficiency targets for the specific power rail being filtered.

Part Context

This component belongs to the ACMP-1566 series of power common mode chokes from Abracon. The series is engineered for robust performance in demanding power electronics applications, offering reliable noise suppression capabilities while maintaining low insertion loss for efficient power transmission.

Replacement Considerations

Consult official manufacturer substitution lists for verified equivalents. Generic replacements may not match the precise impedance curve or current handling capabilities required for critical power filtering applications.
