ACSB-02-T

Overview

The ACSB-02-T is a surface-mount ferrite chip bead manufactured by Abracon LLC. It features a nominal impedance of 90 Ohms at 100 MHz and supports a maximum DC current of 5 A with a low DC resistance of 0.9 mOhms. The component operates within a temperature range of -40°C to +85°C and has a tolerance of ±20%. Its physical dimensions are 8.5 mm in length, 3.1 mm in width, and 2.6 mm in height, utilizing a two-terminal SMD/J-Lead configuration.

Feature Summary

• Provides superior signal attenuation across a broad frequency spectrum extending into the GHz range.
• Engineered for high-current applications with a rated capacity of 5 A and minimal resistive loss.
• Constructed as a lead-free, RoHS-compliant component suitable for environmentally regulated manufacturing processes.

Applications

• High-speed digital signal line filtering
• Power supply noise suppression
• EMI/RFI interference reduction in compact electronic assemblies

Procurement Notes

Verify component authenticity through authorized Abracon distributors or certified partners. Confirm that the received parts match the specified 90 Ohm impedance and 5 A current rating. Ensure storage conditions maintain integrity prior to soldering. Check for any specific handling requirements outlined in the official datasheet to prevent damage during assembly.

Selection Notes

Select this component when designing circuits requiring effective broadband noise suppression without significant voltage drop. The 5 A current rating makes it suitable for power lines, while the 90 Ohm impedance targets common EMI frequencies. Ensure the PCB footprint accommodates the 8.5 x 3.1 mm package dimensions and J-leads.

Part Context

This part belongs to Abracon's Surface Mount Ferrite Chip Beads series. These components are designed to suppress electromagnetic interference in high-density electronic environments. The series offers various impedance values and current ratings to suit different circuit protection needs.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing designs before considering alternative ferrite beads from other manufacturers.

FAQ

What is the operating temperature range for the ACSB-02-T?

The component operates effectively within a temperature range of -40°C to +85°C.

Does the ACSB-02-T meet environmental compliance standards?

Yes, the component is RoHS compliant and lead-free.
