Product Detailed Parameters
- Description：RELAY GEN PURPOSE DPST 10A 5V
- Series：ADJ
- Mfr：Panasonic Electric Works
- Package：Bulk,Box
- Mounting Type：Through Hole
- Coil Voltage：5VDC
- Contact Form：DPST-NC (2 Form B)
- Contact Rating (Current)：10:00 AM
- Switching Voltage：250VAC - Max
- Load - Max Switching：2500VA
- Coil Current：50 mA
- Coil Type：Non Latching
- Features：-
- Termination Style：PC Pin
- Seal Rating：Sealed - Fully
- Coil Insulation：-
- Must Operate Voltage：3.75 VDC
- Must Release Voltage：0.5 VDC
- Operating Temperature：-40°C ~ 70°C
- Contact Material：Silver Tin Oxide (AgSnO), Gold (Au)
- Approval Agency：CQC, cURus, VDE
- Relay Type：General Purpose
- Grade：-
- Qualification：-
- Operate Time：20 ms
- Release Time：20 ms
