ADQ600-48S10-4L

ADQ600-48S10-4L is listed in the DC DC Converters range at ChipApex. The manufacturer field lists ARTESYN / Advanced Energy. Its product description is 600W, 45 - 56VIN, 10V 63A QUARTE. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for ADQ600-48S10-4L

• Description：600W, 45 - 56VIN, 10V 63A QUARTE
• Series：ADQ600 (600W)
• Mfr：ARTESYN / Advanced Energy
• Package：Box
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：45V
• Voltage - Input (Max)：56V
• Voltage - Output 1：10.1V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：63A
• Power (Watts)：636 W
• Voltage - Isolation：750 V
• Applications：ITE (Commercial)
• Features：Adjustable Output, Remote On/Off
• Operating Temperature：-20°C ~ 90°C
• Efficiency：97%
• Mounting Type：Through Hole
• Package / Case：Quarter Brick
• Size / Dimension：2.30" L x 1.45" W x 0.43" H (58.4mm x 36.8mm x 11.0mm)
• Supplier Device Package：Quarter Brick
• Control Features：Enable, Active Low
• Approval Agency：CE, cUL, TUV, UL
• Standard Number：60950-1; 62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for ADQ600-48S10-4L
