AE1250B1398

Overview

The AE1250B1398 is an active RF cavity bandpass filter manufactured by Anatech Electronics Inc. It operates with a center frequency of 1.25 GHz and provides a bandwidth of 100 MHz. The component features a ripple specification of 0.2 dB and utilizes SMA connectors for interface connections. Packaged in a box, this module is designed for radio frequency applications requiring precise signal filtering at the specified center frequency.

Feature Summary

• Cavity construction for stable bandpass filtering performance
• SMA connector interface for standard RF integration
• Low insertion loss ripple characteristic

Applications

• Radio frequency signal processing systems
• Telecommunications infrastructure equipment
• Test and measurement instrumentation

Procurement Notes

Verify part status and datasheet alignment before procurement. Confirm SMA connector compatibility and mechanical dimensions for your specific assembly requirements. Ensure the center frequency and bandwidth specifications match your system design constraints to avoid integration issues.

Selection Notes

Select this component when a 1.25 GHz center frequency with 100 MHz bandwidth is required. Consider the SMA interface and cavity construction for environmental stability. Evaluate the 0.2 dB ripple specification against your system's signal integrity needs.

Part Context

This model belongs to the Anatech Electronics Inc. RF filter family, specifically designed as a modular bandpass unit. It serves as a specialized component for filtering signals within the microwave frequency range, offering a fixed center frequency solution for dedicated RF applications.

Replacement Considerations

Consult official documentation for direct substitutes. Verify that any replacement maintains the 1.25 GHz center frequency, 100 MHz bandwidth, and SMA connector type to ensure functional equivalence.
