AE155B9993-BNC

Overview

The AE155B9993-BNC is a bandpass RF filter manufactured by Anatech Electronics Inc. It features a center frequency of 155 MHz and a bandwidth of 40 MHz. The component has an insertion loss of 1 dB and utilizes SMA connectors. It is housed in a module package.

Feature Summary

• Provides signal filtering with a 155 MHz center frequency
• Supports a 40 MHz signal bandwidth for communication range
• Utilizes SMA connector interfaces

Applications

• Radio frequency signal processing
• Broadband communication systems
• RF filter modules

Procurement Notes

Verify the specific connector type and package configuration against official manufacturer documentation before procurement. Ensure the part number matches the required electrical specifications, particularly the 155 MHz center frequency and 40 MHz bandwidth. Confirm interface compatibility with existing system designs to avoid integration issues.

Selection Notes

Select this component when a fixed 155 MHz bandpass characteristic is required. Consider the 40 MHz bandwidth and 1 dB insertion loss for system performance requirements. Verify that the SMA connector interface aligns with the circuit board layout and interconnect needs.

Part Context

This part belongs to the Anatech Electronics Inc. RF filter series. It is designed as a module for radio frequency applications. The product provides specific bandpass filtering capabilities centered at 155 MHz.

FAQ

What is the center frequency of the AE155B9993-BNC?

The center frequency is 155 MHz.

What type of connectors does this filter use?

It uses SMA connectors.
