Product Detailed Parameters
- Description：RF FILTER HIGH PASS 2GHZ MODULE
- Series：-
- Mfr：Anatech Electronics Inc.
- Package：Box
- Frequency：2GHz (Cutoff)
- Bandwidth：8GHz
- Filter Type：High Pass
- Ripple：-
- Insertion Loss：2dB
- Mounting Type：Chassis Mount
- Package / Case：Module, SMA Connectors
- Size / Dimension：1.000" L x 0.750" W (25.40mm x 19.05mm)
- Height (Max)：0.750" (19.05mm)
Download product information
Overview
The AE2000H9800 is a high-pass RF filter module manufactured by Anatech Electronics Inc. It features a cutoff frequency of 2 GHz and an operational bandwidth extending to 8 GHz. The component utilizes SMA connectors for interface compatibility. In the passband, it maintains an insertion loss of 2 dB. This module is designed for radio frequency applications requiring signal filtering within the specified microwave range.
Feature Summary
- High-pass filtering capability with defined cutoff characteristics
- Module form factor with integrated SMA connectors
- Designed for radio frequency signal processing
Applications
- Radio frequency circuit filtering
- Microwave signal processing systems
- Communication equipment signal conditioning
Procurement Notes
Verify the specific datasheet for the AE2000H9800 to confirm mechanical dimensions and connector details. Ensure the required cutoff frequency and insertion loss specifications align with your system design requirements before procurement. Cross-reference the manufacturer part number to avoid confusion with similar models in the Anatech product line.
Selection Notes
Select this component when a 2 GHz high-pass response is required in a modular format. Consider the SMA interface for standard test and measurement or production environments. Evaluate the 2 dB insertion loss against system power budget constraints. Confirm that the 8 GHz bandwidth covers the necessary signal spectrum without excessive attenuation in the passband.
Part Context
Anatech Electronics Inc. specializes in RF and microwave filters. The AE2000H9800 belongs to their high-pass filter series. These components are typically used in professional RF engineering contexts. The company focuses on custom and standard filter designs for various frequency ranges.
Replacement Considerations
Consult official Anatech documentation for direct substitutes. Verify electrical parameters such as cutoff frequency and insertion loss match exactly. Check connector type compatibility if replacing in existing assemblies.
