AE2097B1360

Overview

The AE2097B1360 is a multi-frequency cavity bandpass filter manufactured by Anatech Electronics Inc. It operates with a center frequency of 2.097 GHz and provides a bandwidth of 12 MHz. The component features an insertion loss of 2.5 dB and minimal ripple. It utilizes SMA connectors for interface connections and is supplied in a box package.

Feature Summary

• Cavity construction for stable RF filtering performance
• Bandpass configuration with defined center frequency and bandwidth
• SMA connector interface for signal transmission

Applications

• RF signal processing systems
• Communication equipment requiring specific frequency band selection
• Test and measurement instrumentation

Procurement Notes

Verify the exact center frequency and bandwidth requirements against the 2.097 GHz and 12 MHz specifications before ordering. Confirm that SMA connectors are compatible with your system interface. Ensure the 2.5 dB insertion loss meets your system's power budget constraints. Check for any specific environmental or mounting requirements associated with the cavity design.

Selection Notes

Select this component when a fixed center frequency of 2.097 GHz is required. The 12 MHz bandwidth defines the passband width. Consider the 2.5 dB insertion loss impact on signal strength. Verify compatibility with SMA interfaces. Evaluate if the cavity form factor fits within the available space constraints of the assembly.

Part Context

This part belongs to the Anatech series of Multi-frequency Cavity Bandpass filters. It is one of several products launched by Anatech Electronics Inc., including models AE3910B11469 and AE1750B11251, each targeting different frequency bands. The series focuses on providing specialized RF filtering solutions using cavity technology.

FAQ

What is the center frequency of the AE2097B1360?

The center frequency is 2.097 GHz.

What type of connectors does this filter use?

It uses SMA connectors.
