AE2585B1368

Overview

The AE2585B1368 is a cavity bandpass filter manufactured by Anatech Electronics Inc. It operates with a center frequency of 2585 MHz and provides a minimum bandwidth of 10 MHz, covering the 2580-2590 MHz passband. The component features a maximum insertion loss of 3.0 dB and a maximum VSWR of 1.50:1. It utilizes SMA connectors for interface connections.

Feature Summary

• Cavity construction for RF filtering
• SMA connector interfaces

Applications

• Radio frequency signal processing
• Microwave communication systems

Procurement Notes

Verify the specific datasheet version to confirm RoHS3 compliance and MSL level 1 status. Ensure that the SMA connector type matches the system requirements. Cross-reference the electrical specifications against the application needs to confirm suitability for the intended frequency range.

Selection Notes

Select this component when a fixed center frequency of 2585 MHz is required. Consider the 10 MHz bandwidth constraint for signal isolation needs. Evaluate the 3.0 dB insertion loss limit against system power budgets. Confirm compatibility with existing SMA interconnects.

Part Context

Anatech Electronics Inc. specializes in RF and microwave filters. This model belongs to their cavity filter series designed for specific frequency bands. The company focuses on design and manufacturing of such components for industrial applications.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation.
