AE420B11630

Overview

The AE420B11630 is a cavity bandpass RF filter manufactured by Anatech Electronics Inc. It operates with a center frequency of 420 MHz and provides a bandwidth of 20 MHz. The module features SMA connectors for interface connectivity. This component is designed for radio frequency applications requiring specific signal filtering characteristics within the defined frequency range.

Feature Summary

• Cavity construction for stable RF performance
• Bandpass filtering capability at 420 MHz
• Integrated SMA connector interfaces

Applications

• Radio frequency signal processing
• Communication system filtering
• Test and measurement equipment

Procurement Notes

Verify the exact part number AE420B11630 against official Anatech Electronics documentation to ensure compatibility. Confirm that the SMA connector type and cavity construction meet your specific RF requirements. Check for RoHS compliance status if environmental regulations apply to your deployment. Ensure the 420 MHz center frequency aligns with your system design specifications before procurement.

Selection Notes

Select this component when a fixed 420 MHz center frequency with 20 MHz bandwidth is required. The SMA interface dictates connector compatibility with existing cabling. Consider the cavity construction for thermal and mechanical stability in RF environments. Verify that the module form factor fits within your system constraints.

Part Context

Anatech Electronics Inc. specializes in RF and microwave filters, including cavity designs. The AE420B11630 belongs to their line of bandpass modules. These components are typically used in specialized communication and testing applications where precise frequency selection is critical. The company focuses on custom and standard RF solutions.

Replacement Considerations

Consult official Anatech Electronics substitution guides for verified equivalents. Generic replacements may not match the cavity construction or SMA interface specifications. Ensure any substitute maintains the 420 MHz center frequency and 20 MHz bandwidth parameters.
