AE6000H9761

Overview

The AE6000H9761 is a high-pass RF filter module manufactured by Anatech Electronics Inc. It features a cutoff frequency of 6 GHz and operates within a passband ranging from 6 GHz to 18 GHz. The component specifies a maximum insertion loss of 1 dB in the passband region. It utilizes SMA connectors for interface connections, ensuring compatibility with standard RF test and measurement setups. This LC-based filter design provides efficient signal filtering characteristics suitable for microwave applications requiring precise frequency discrimination above the specified cutoff threshold.

Feature Summary

• High-pass filtering capability with a defined 6 GHz cutoff frequency
• Operational bandwidth extending from 6 GHz to 18 GHz
• Low insertion loss specification of 1 dB in the passband
• Integrated SMA connector interfaces for direct system integration

Applications

• RF signal conditioning in microwave communication systems
• Harmonic suppression in test and measurement equipment
• Frequency selection in radar subsystems

Procurement Notes

Verify the specific datasheet version when ordering, as manufacturer specifications may undergo revisions. Confirm that the SMA connector gender and mating requirements align with your existing cabling infrastructure. Ensure environmental conditions such as temperature and humidity remain within the operational limits defined in the official product documentation to maintain performance integrity.

Selection Notes

Select this component when a fixed 6 GHz high-pass characteristic is required for frequencies up to 18 GHz. The 1 dB insertion loss limit makes it suitable for applications where signal attenuation must be minimized in the desired band. Consider the physical form factor and SMA interface compatibility before integration into larger RF assemblies or test fixtures.

Part Context

Anatech Electronics Inc. specializes in the design and manufacturing of RF and microwave filters. Founded in 1990 and ISO 9001:2015 certified, the company produces components like the AE6000H9761 for professional engineering and industrial markets. These products are typically distributed through authorized electronic component suppliers rather than general retail channels.

Replacement Considerations

No publicly confirmed substitute part numbers are available in the provided documentation. Engineers should consult Anatech Electronics directly for potential cross-reference options or custom modifications if exact replacement is required.
