AE915NS2095

Overview

The AE915NS2095 is a 915 MHz center frequency RF bandstop filter module manufactured by Anatech Electronics Inc. It features a 26 MHz bandwidth and provides greater than 20 dB attenuation within the 902-928 MHz notch band. The device maintains low insertion loss in the 500-850 MHz passband region. It utilizes SMA connectors for interface connections, designed for integration into radio frequency communication systems requiring specific frequency rejection.

Feature Summary

• Provides high attenuation in the 902-928 MHz range
• Maintains signal integrity in the 500-850 MHz passband
• Utilizes SMA connector interfaces

Applications

• Military communication systems
• Commercial communication systems
• RF interference suppression

Procurement Notes

Verify the exact datasheet version from Anatech Electronics Inc. or authorized distributors to confirm mechanical dimensions and connector specifications. Ensure compatibility with system impedance requirements before procurement. Cross-reference part numbers carefully as suffixes may indicate variations in packaging or testing standards.

Selection Notes

Select this component when precise rejection of the 902-928 MHz ISM band is required while preserving signals below 850 MHz. Consider the SMA interface type and module form factor for board integration. Verify thermal and power handling capabilities against specific application loads.

Part Context

Anatech Electronics Inc. specializes in RF and microwave filters for military and commercial sectors. This model belongs to their LC bandstop filter series, designed for robust performance in demanding environments. The company holds ISO 9001:2015 certification, ensuring quality manufacturing processes for these passive components.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult Anatech Electronics Inc. directly for equivalent models or custom design alternatives if this specific part number is unavailable.
