AECC0502GBS-S

Antennas RF Overview

The AECC0502GBS-S is an ultra-low profile active GNSS antenna manufactured by Abracon LLC. It supports multiple global navigation satellite systems including GPS, GLONASS, Galileo, Beidou, and QZSS. The component features a right-hand circular polarization (RHCP) design with a 50 Ohm impedance. It utilizes an SMA male connector for termination and provides IP67 ingress protection rating for outdoor durability. The antenna operates across seven frequency bands starting from 1.20714 GHz, ensuring comprehensive signal reception capabilities for diverse positioning applications.

Antennas RF Feature Summary

• Supports multi-constellation GNSS signals including GPS, GLONASS, Galileo, Beidou, and QZSS
• Features right-hand circular polarization for optimal signal acquisition
• Provides IP67 rated environmental protection for outdoor deployment
• Utilizes an ultra-low profile design suitable for space-constrained installations

Antennas RF Applications

• Global Navigation Satellite System (GNSS) positioning modules
• Outdoor vehicle tracking and telematics systems
• Maritime and aviation navigation equipment
• Geospatial surveying and mapping devices
• IoT location-based services requiring high reliability

Antennas RF Procurement Notes

Verify the specific order suffix to confirm connector type and cable length specifications. Ensure compatibility with the host system's RF interface requirements. Confirm that the SMA male termination matches the receiving board or cable assembly. Check environmental ratings against installation site conditions. Validate frequency band support against regional satellite constellations in use.

Antennas RF Selection Notes

Select this model when multi-constellation support is required for improved accuracy and availability. Consider the IP67 rating for harsh outdoor environments where moisture and dust resistance are critical. The ultra-low profile form factor makes it suitable for applications with strict height limitations. Evaluate the SMA male connector requirement against existing infrastructure. Ensure the operating frequency range aligns with target satellite signals.

Antennas RF Part Context

This component belongs to Abracon's GNSS antenna portfolio, designed for high-performance positioning applications. It complements other RF solutions by providing reliable signal reception for complex satellite networks. The product line emphasizes durability and low profile designs for modern embedded systems. It serves as a critical interface between satellite signals and baseband processing units.

Antennas RF Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify mechanical dimensions and mounting hole patterns if considering alternative antennas. Ensure equivalent gain and noise figure specifications are met by any potential replacement. Check connector polarity and impedance matching to maintain signal integrity.
