AECP0401G4ZS-3000S

Antennas RF Overview

The Abracon AECP0401G4ZS-3000S is an automotive-grade active external puck antenna designed for GNSS applications including GPS, GLONASS, BeiDou, and QZSS. It features a magnetic base for easy installation and an IP67 rating for environmental protection. The unit includes a 3000 mm RG174 cable terminated with an SMA male connector. Key electrical specifications include a gain of 5 dBic, an impedance of 50 Ohms, and a physical height of 15.2 mm.

Antennas RF Feature Summary

• Automotive-grade construction certified under IATF 16949 standards
• IP67 rated enclosure ensuring resistance to dust and water ingress
• Integrated magnetic mounting system for rapid deployment
• Active design supporting multiple global satellite navigation constellations

Antennas RF Applications

• Vehicle telematics systems
• Fleet tracking solutions
• Automotive navigation units
• GNSS positioning modules in harsh environments

Antennas RF Procurement Notes

Verify the specific suffix configuration against the official Abracon datasheet to ensure compatibility with required cable lengths and connector types. Confirm that the selected variant meets the necessary automotive qualification standards for your target application environment. Cross-reference part numbers carefully as minor suffix changes may alter physical dimensions or performance characteristics.

Antennas RF Selection Notes

Select this model when automotive reliability and environmental sealing are critical requirements. The active puck design offers superior signal acquisition compared to passive alternatives. Ensure the host device supports the required frequency bands for the intended satellite systems. Verify cable routing constraints given the fixed 3000 mm length provided in this specific configuration.

Antennas RF Part Context

This component belongs to Abracon's AECP series of GNSS antennas specifically engineered for the automotive sector. The series provides customizable options for cable and connector configurations while maintaining consistent form factors. These antennas are designed to integrate seamlessly into vehicle roof-mounted or interior installations requiring robust satellite connectivity.

Antennas RF Replacement Considerations

Direct substitutes include other models from the AECP series with matching connector types and cable lengths. Verify that any replacement maintains the same IATF 16949 certification level. Ensure the alternative part supports all required GNSS constellations such as GPS, GLONASS, and BeiDou for equivalent functionality.
