AETC01M02XS-SS

$15.32

Description：LTE 4G/5G & WI-FI 6E WHIP ANTENN
Series：AETC
Mfr：Abracon LLC
Package：Bag

SKU:5a591b9fea65 Category: RF Antennas Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AETC01M02XS-SS is listed in the Antennas RF range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is LTE 4G/5G & WI-FI 6E WHIP ANTENN. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for AETC01M02XS-SS

Description：LTE 4G/5G & WI-FI 6E WHIP ANTENN
Series：AETC
Mfr：Abracon LLC
Package：Bag
RF Family/Standard：802.15.4, Bluetooth, Cellular, WiFi
Frequency Group：Wide Band
Frequency (Center/Band)：788.5MHz, 2.071GHz, 4.575GHz, 6.5GHz
Frequency Range：617MHz ~ 960MHz, 1.452GHz ~ 2.69GHz, 3.3GHz ~ 5.85GHz, 5.85GHz ~ 7.15GHz
Antenna Type：Whip, Straight
Number of Bands：4
VSWR：2.5, 2, 2, 2.5
Return Loss：12dB
Gain：1dBi, 4dBi, 3dBi, 3dBi
Features：Cable - 1.5m
Termination：SMA Male
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.213" (5.40mm)
Applications：4G, 5G, Bluetooth, LTE, Wi-Fi, WLAN, Zigbee™
Power - Max：500 mW

Antennas RF datasheet and documents for AETC01M02XS-SS

AETC01M02XS-SS

Antennas RF Overview

The AETC01M02XS-SS is a broadband whip antenna designed for surface mount installation. It supports multiple frequency bands including 617MHz to 960MHz, 1.452GHz to 2.69GHz, 3.3GHz to 5.85GHz, and 5.85GHz to 7.15GHz. The component features an SMA male connector and offers a gain of 2dBi across its operational spectrum. With a maximum height of 5.335 inches (135.50mm), it provides reliable RF performance for wireless communication applications.

Antennas RF Feature Summary

Supports LTE, 4G, 5G, Wi-Fi 6E, Bluetooth, WLAN, and Zigbee protocols
Surface mount design with integrated SMA male connector
Broadband operation covering cellular and unlicensed ISM bands

Antennas RF Applications

IoT devices requiring multi-band connectivity
Industrial wireless gateways
Smart home hubs supporting Wi-Fi 6E and Bluetooth

Antennas RF Procurement Notes

Verify the specific datasheet revision to confirm mechanical dimensions and soldering recommendations. Ensure the SMA connector type matches the host board interface requirements. Check RoHS compliance status if operating in regulated environments. Confirm availability through authorized distributors as supply chain conditions may vary.

Antennas RF Selection Notes

Select this model when surface mounting is required for high-gain omnidirectional coverage. Consider the physical height constraint of 135.50mm during enclosure design. Ideal for applications needing simultaneous support for cellular and Wi-Fi frequencies without external matching networks.

Antennas RF Part Context

Part of the AETC series from Abracon LLC, focusing on compact, high-performance RF solutions. This series targets modern wireless standards requiring broad frequency coverage in small form factors.
