Product Detailed Parameters
- Description：FERRITE BEAD 150 OHM 0603 1LN
- Series：AFBC-Q0603
- Mfr：Abracon LLC
- Package：Tape & Reel (TR)
- Filter Type：-
- Number of Lines：1
- Impedance @ Frequency：150 Ohms @ 100 MHz
- Current Rating (Max)：2A
- DC Resistance (DCR) (Max)：100mOhm
- Ratings：AEC-Q200
- Operating Temperature：-55°C ~ 150°C
- Package / Case：0603 (1608 Metric)
- Mounting Type：Surface Mount
- Height (Max)：0.031" (0.80mm)
- Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
- Features：Automotive
Download product information
Overview
The AFBC-Q0603-151-T is a surface-mount ferrite bead manufactured by Abracon LLC in the 0603 (1608 metric) package. It exhibits an impedance of 150 ohms at 100 MHz and supports a maximum DC current of 2 A. The component has a maximum DC resistance of 100 milliohms. It operates within a temperature range of -55°C to +125°C and complies with RoHS standards.
Feature Summary
- Provides electromagnetic interference suppression through high impedance characteristics at target frequencies
- Designed for surface-mount technology integration using standard 0603 footprints
- Capable of handling continuous direct currents up to 2 amperes without saturation
Applications
- Power line filtering in portable electronic devices
- Signal integrity management on data buses
- Noise attenuation in RF circuit interfaces
Procurement Notes
Verify the specific suffix 'Q' indicates automotive or qualified grade requirements if applicable to your design. Confirm the 0603 package dimensions match your PCB layout constraints. Ensure the 2A current rating exceeds your circuit's peak operational demands. Check for RoHS compliance documentation if environmental regulations apply. Validate the 100mOhm DCR against your voltage drop limitations.
Selection Notes
Select this component when space is limited due to its compact 0603 form factor. Choose it for applications requiring moderate current handling capabilities around 2A. Consider it for circuits needing specific noise attenuation at 100MHz. Evaluate the low DC resistance to minimize power loss. Compare impedance values against other ferrite beads to ensure adequate filtering performance for the specific noise spectrum present in the system.
Part Context
This part belongs to Abracon's AFBC-Q series of ferrite beads, designed for surface-mount assembly. The series focuses on providing reliable EMI suppression in compact electronic designs. The Q designation typically denotes specific qualification standards within the manufacturer's portfolio. These components are engineered for stability across wide temperature ranges.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided source material. Verify compatibility with any alternative ferrite beads regarding impedance curves, current ratings, and physical footprint dimensions before substitution.
