Product Detailed Parameters
- Description：FERRITE BEAD 150 OHM 1206 1LN
- Series：AFBC-Q3211
- Mfr：Abracon LLC
- Package：Tape & Reel (TR)
- Filter Type：-
- Number of Lines：1
- Impedance @ Frequency：150 Ohms @ 100 MHz
- Current Rating (Max)：2A
- DC Resistance (DCR) (Max)：100mOhm
- Ratings：AEC-Q200
- Operating Temperature：-55°C ~ 150°C
- Package / Case：1206 (3216 Metric)
- Mounting Type：Surface Mount
- Height (Max)：0.043" (1.10mm)
- Size / Dimension：0.126" L x 0.063" W (3.20mm x 1.60mm)
- Features：Automotive
Download product information
Overview
The AFBC-Q3211-151-T is a ferrite bead from the Abracon AFBC-Q series, designed for electromagnetic interference suppression in surface-mount applications. It features a 1206 (3216 Metric) package with a nominal impedance of 150 Ohms at 100 MHz and a tolerance of ±25%. The component supports a maximum DC current of 2A and exhibits a maximum DC resistance of 100 milliohms. It operates within a temperature range of -55°C to +150°C and complies with RoHS standards.
Feature Summary
- Provides effective high-frequency noise attenuation through controlled impedance characteristics
- Supports high-current operation suitable for power line filtering applications
- Utilizes a compact 1206 surface-mount footprint for space-constrained PCB designs
Applications
- Power supply output filtering
- Digital signal line noise suppression
- RF circuit interference mitigation
Procurement Notes
Verify the specific suffix and packaging configuration against the manufacturer's latest datasheet before ordering. Confirm availability status as distribution channels may vary. Ensure the selected variant meets all electrical requirements including impedance, current rating, and thermal performance for the intended application environment.
Selection Notes
Select this component based on its 150 Ohm impedance at 100 MHz and 2A current handling capability. Evaluate the 100 milliohm DC resistance to ensure minimal voltage drop in the target circuit. Consider the 1206 package dimensions for board layout compatibility and verify thermal stability within the specified -55°C to +150°C operating range.
Part Context
This part belongs to the Abracon AFBC-Q series of ferrite beads, which are engineered for general-purpose EMI suppression. The series offers various impedance values and current ratings in standard SMD packages. The AFBC-Q3211-151-T specifically addresses mid-range noise filtering needs in consumer electronics and industrial equipment.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's official cross-reference tools or equivalent ferrite bead specifications for compatible alternatives.
