AFCC100250UKT8T

Overview

The KEMET AFCC100250UKT8T is an axial film feedthrough filter designed for EMI suppression. It features a 630V DC rating and integrates a 100nF capacitor with a 10 Ohm series resistor. The component utilizes a polypropylene dielectric and operates within a temperature range of -40°C to +105°C. It complies with IEC 60384-27 standards and offers high surge current capability, making it suitable for demanding power line filtering applications.

Feature Summary

• Integrates a 100nF capacitance with a 10 Ohm series resistor in a single axial package
• Provides effective EMI suppression through combined capacitive and resistive filtering
• Supports high surge currents for robust performance in power line environments

Applications

• Power supply input filtering
• EMI suppression on AC/DC lines
• Industrial equipment noise reduction

Procurement Notes

Verify the specific suffix T8T against official KEMET documentation to confirm lead time and packaging details. Ensure the 630V DC rating and 10 Ohm resistance align with circuit requirements. Confirm compliance with IEC 60384-27 for your application standards.

Selection Notes

Select this component when both capacitive decoupling and resistive damping are required in a single axial form factor. The 100nF value and 10 Ohm resistance provide a balanced approach for high-frequency noise attenuation. Consider the 630V DC rating for safety margins in mains-connected circuits.

Part Context

This part belongs to the AFCC series of axial film feedthrough filters from KEMET. These components combine metallized polypropylene film capacitors with integrated resistors. The series is designed for compact EMI filtering solutions where space and component count are critical constraints.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Consult KEMET technical support for direct equivalents or cross-references.
