AFPI100410HFT1S

Overview

The AFPI100410HFT1S is a feed-through film filter manufactured by KEMET. It features an axial configuration designed for through-hole mounting. The component integrates a 5 µF capacitance value with a 100 V voltage rating. This construction provides effective electromagnetic interference suppression in electronic circuits requiring robust filtering capabilities.

Feature Summary

• Integrates feed-through filtering technology within a single compact component
• Utilizes metallized polypropylene film dielectric for stable performance
• Designed for direct wire connection via axial leads

Applications

• Power supply input filtering
• Electromagnetic interference suppression in industrial equipment
• Signal conditioning in sensitive electronic systems

Procurement Notes

Verify the specific manufacturer datasheet to confirm exact electrical characteristics and mechanical dimensions. Ensure compatibility with existing circuit board layouts and thermal management requirements before integration into final designs.

Selection Notes

Select this component when high capacitance values are required in a feed-through form factor. Consider the axial lead style for applications where direct wire termination is preferred over surface mount or standard radial configurations.

Part Context

This part belongs to KEMET's AFPI series of feed-through filters. These components combine capacitive filtering with structural integrity, offering a solution for noise reduction in environments where space constraints or specific mounting orientations necessitate a feed-through design approach.
