Product Detailed Parameters
- Description：FILTER FILM FEED THROUGH AXL
- Series：AFPI 160
- Mfr：KEMET
- Package：Bulk
- Voltage - Rated：600V
- Current：16 A
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Package / Case：Axial, Bushing
- Size / Dimension：0.630" Dia x 1.339" L (16.00mm x 34.00mm)
- Capacitance：2500 pF
- Tolerance：-
- DC Resistance (DCR) (Max)：6mOhm
- Insertion Loss：83dB @ 100MHz
- Temperature Coefficient：-
- Ratings：-
- Height (Max)：-
- Thread Size：-
Download product information
Overview
The KEMET AFPI160150TMW3N is a feed-through capacitor from the AFPI series, rated at 2500 pF capacitance and 600V DC voltage. It supports a continuous current of 16 A with an insertion loss of 83 dB at 100 MHz. The component features a low resistance of 6 mOhm and utilizes chassis mounting for secure installation.
Feature Summary
- Provides high-frequency electromagnetic interference suppression through significant insertion loss performance.
- Designed for robust power handling capabilities suitable for demanding electrical environments.
- Constructed as a feed-through unit to facilitate direct panel or chassis integration.
Applications
- Military and aerospace electronic systems requiring reliable filtering
- Chassis-mounted power distribution units
- High-reliability industrial control equipment
Procurement Notes
Verify part status carefully as this item may be subject to obsolescence notifications. Confirm that the specific suffix matches the required technical specifications for your design. Ensure compatibility with existing chassis mounting hardware and verify that the voltage and current ratings align with the system's operational requirements before procurement.
Selection Notes
Select this component when high-current feed-through filtering is required in space-constrained chassis applications. The 600V rating and 16A capacity define its operational limits. Consider the 83dB insertion loss for EMI mitigation needs. Verify that the axial bushing form factor fits the available panel cutouts and mounting constraints of the target enclosure.
Part Context
This component belongs to the KEMET AFPI series of feed-through capacitors. These parts are engineered for high-reliability applications where robust electromagnetic interference suppression and high current handling are critical. The series typically serves military, aerospace, and industrial sectors requiring durable passive components.
Replacement Considerations
Check official KEMET documentation for direct substitutes within the AFPI series. Verify that any alternative maintains the same 2500 pF capacitance, 600V rating, and 16A current capacity. Ensure mechanical dimensions and mounting styles remain compatible with the existing chassis design.
