AGDT-3738

$3.36

Description：SMT Gate Drive Transformer
Series：AGDT-3738
Mfr：Allied Components International
Package：Tape & Reel (TR)

SKU:e09621f8941d Category: Pulse Transformers Brand: Allied Components International

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：SMT Gate Drive Transformer
Series：AGDT-3738
Mfr：Allied Components International
Package：Tape & Reel (TR)
Transformer Type：Gate Drive
Inductance：1.2mH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1:01
Mounting Type：Surface Mount
Size / Dimension：0.330" L x 0.230" W (8.38mm x 5.84mm)
Height - Seated (Max)：0.295" (7.49mm)
Operating Temperature：-40°C ~ 85°C
Grade：-
Qualification：-

Download product information

AGDT-3738

Overview

The AGDT-3738 is a surface-mount gate drive pulse transformer manufactured by Allied Components International. It features a 1:1 turns ratio and an inductance of 1.2mH. The component is housed in an SMD-8P package with dimensions of 8.6x8.4mm. It operates within a temperature range of -40°C to 85°C and is available in tape and reel packaging.

Feature Summary

Surface mount construction for automated assembly
Isolated gate drive signal transmission
RoHS compliant manufacturing

Applications

Gate drive circuits for power switches
High-frequency isolation applications
Power supply control systems

Procurement Notes

Verify the manufacturer part number AGDT-3738 against official Allied Components International documentation to ensure authenticity. Confirm that the received components match the specified SMD-8P package dimensions and RoHS compliance status. Check for any specific handling requirements related to the tape and reel format during storage and assembly processes.

Selection Notes

Select this component when a compact, surface-mount solution for isolated gate driving is required. The 1:1 ratio suits direct coupling applications. Ensure the operating environment stays within the -40°C to 85°C range. Verify that the 1.2mH inductance meets the circuit's timing requirements.

Part Context

This device belongs to the AGDT series of pulse transformers designed for electronic switching applications. It provides electrical isolation between control logic and power stages. The SMD-8P form factor allows for space-constrained PCB layouts compared to through-hole alternatives.

Replacement Considerations

Consult official cross-reference data from Allied Components International for verified substitutes. Generic equivalents may not match the specific 1.2mH inductance or package footprint.
