AH-30

Overview

The Ohmite AH-30 is a single-phase, dual-stage power line filter designed for high-performance noise suppression. It operates at a rated voltage of 250VAC and supports a current capacity of 1 Ampere at 50/60Hz frequencies. The unit features a compact form factor suitable for integration into AC power input stages to mitigate electromagnetic interference.

Feature Summary

• Dual-stage filtering architecture for enhanced attenuation
• Single-phase configuration for standard AC applications
• High-performance design for effective noise reduction

Applications

• AC power line noise suppression
• Electromagnetic interference mitigation in electronic equipment
• Power input stage filtering for sensitive circuits

Procurement Notes

Verify the specific part number against the manufacturer's official documentation to ensure compatibility with your system requirements. Confirm that the electrical ratings, including voltage and current limits, align with your application's operational parameters before procurement.

Selection Notes

Select this component when a compact, single-phase solution is required for attenuating conducted emissions in low-current AC environments. Ensure the operating voltage does not exceed 250VAC and the load current remains within the 1Amp limit to maintain optimal performance and safety standards.

Part Context

This component belongs to Ohmite's power line filter series, which focuses on providing reliable noise suppression solutions. The AH-30 specifically addresses the need for efficient filtering in space-constrained applications requiring single-phase AC protection.

Replacement Considerations

Consult Ohmite's official cross-reference guides or distributor databases for verified substitute models. Ensure any replacement maintains identical electrical specifications and physical dimensions to guarantee seamless integration without circuit modification.
