AIF50B300-L

AIF50B300-L is listed in the DC DC Converters range at ChipApex. The manufacturer field lists ARTESYN / Advanced Energy. Its product description is DC DC CONVERTER 12V 600W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AIF50B300-L

• Description：DC DC CONVERTER 12V 600W
• Series：AIF (600W)
• Mfr：ARTESYN / Advanced Energy
• Package：Tray
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：250V
• Voltage - Input (Max)：420V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：50A
• Power (Watts)：600 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, OVP
• Operating Temperature：-20°C ~ 100°C
• Efficiency：90%
• Mounting Type：Through Hole
• Package / Case：Module
• Size / Dimension：4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for AIF50B300-L
