AIMC-02UHQ-0N3S-T

AIMC-02UHQ-0N3S-T is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is IND 0.3NH 650 MA 20MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for AIMC-02UHQ-0N3S-T

• Description：IND 0.3NH 650 MA 20MOHM SMD
• Series：AIMC-02UHQ
• Mfr：Abracon LLC
• Package：Tape & Reel (TR)
• Type：Multilayer
• Material - Core：Ceramic
• Inductance：0.3 nH
• Tolerance：±0.3nH
• Current Rating (Amps)：650 mA
• Current - Saturation (Isat)：-
• Shielding：Shielded
• DC Resistance (DCR)：20mOhm Max
• Q @ Freq：8 @ 500MHz
• Frequency - Self Resonant：14GHz
• Ratings：-
• Operating Temperature：-55°C ~ 125°C
• Inductance Frequency - Test：500 MHz
• Mounting Type：Surface Mount
• Package / Case：008004 (0201 Metric)
• Supplier Device Package：008004 (0201 Metric)
• Size / Dimension：0.010" L x 0.005" W (0.25mm x 0.13mm)
• Height - Seated (Max)：0.009" (0.22mm)
• Features：-

Fixed Inductors datasheet and documents for AIMC-02UHQ-0N3S-T
