AIMC-Q0201HQ-11NH-T

$0.03

Description：IND 11NH 0.25A 800MOHM
Series：AIMC-Q0201HQ
Mfr：Abracon LLC
Package：Tape & Reel (TR)

SKU:3f8a8bb51ce1 Category: Fixed Inductors Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AIMC-Q0201HQ-11NH-T is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is IND 11NH 0.25A 800MOHM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for AIMC-Q0201HQ-11NH-T

Description：IND 11NH 0.25A 800MOHM
Series：AIMC-Q0201HQ
Mfr：Abracon LLC
Package：Tape & Reel (TR)
Type：Multilayer
Material - Core：Ceramic
Inductance：11 nH
Tolerance：±3%
Current Rating (Amps)：250 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：800mOhm Max
Q @ Freq：14 @ 500MHz
Frequency - Self Resonant：2.9GHz
Ratings：AEC-Q200
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：500 MHz
Mounting Type：Surface Mount
Package / Case：0201 (0603 Metric)
Supplier Device Package：0201 (0603 Metric)
Size / Dimension：0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max)：0.012" (0.30mm)
Features：-

Fixed Inductors datasheet and documents for AIMC-Q0201HQ-11NH-T

AIMC-Q0201HQ-11NH-T

Fixed Inductors Overview

The AIMC-Q0201HQ-11NH-T is a fixed multilayer ceramic chip inductor from the Abracon AIMC-Q series, designed for surface-mount applications. It features an inductance of 11 nH with a tolerance of ±0.5 nH. The component supports a maximum DC current of 300 mA and has a maximum DC resistance of 600 mOhms. It operates within a temperature range of -55°C to +125°C. The self-resonant frequency is 2.9 GHz, and it meets AEC-Q200 Grade 1 qualification standards.

Fixed Inductors Feature Summary

AEC-Q200 Grade 1 qualified for automotive reliability
High self-resonant frequency for RF signal integrity
Multilayer ceramic construction for compact SMD mounting

Fixed Inductors Applications

Automotive RF filtering circuits
High-frequency impedance matching networks
Signal conditioning in automotive electronics

Fixed Inductors Procurement Notes

Verify that the specific suffix 'T' indicates tape-and-reel packaging as per manufacturer documentation. Confirm AEC-Q200 compliance status directly with Abracon or authorized distributors, as this qualification is critical for automotive supply chain requirements. Ensure the part number matches the exact inductance value of 11 nH to avoid circuit mismatch.

Fixed Inductors Selection Notes

Select this component when a small 0201 footprint is required for high-frequency automotive applications. The 11 nH value suits specific RF tuning needs where higher inductance is unnecessary. Consider the 300 mA current rating against the application's peak current demands. The AEC-Q200 qualification makes it suitable for environments requiring strict automotive reliability standards compared to standard commercial grade parts.

Fixed Inductors Part Context

This part belongs to the AIMC-Q series, which is specifically engineered for automotive electronic systems. The series emphasizes robustness and compliance with automotive quality standards like AEC-Q200. The Q0201 package size allows for dense PCB layouts in modern automotive modules where space is limited. It represents a specialized subset of Abracon's broader inductor portfolio focused on vehicular electronics.
