AIMC-Q0402-0N7B-T

Fixed Inductors Overview

The AIMC-Q0402-0N7B-T is a fixed multilayer ceramic chip inductor from Abracon LLC, designed for surface-mount applications. It features an inductance of 0.7 nH with a tolerance of ±0.1 nH. The component has a maximum DC resistance of 80 mOhms and a rated current of 1 A. It operates within a temperature range of -55°C to +125°C. The package dimensions are 1.00 mm in length, 0.50 mm in width, and a maximum height of 0.37 mm.

Fixed Inductors Feature Summary

• Compact 0402 footprint enables tight layout integration in RF networks
• Multilayer ceramic construction provides stability in high-frequency circuits
• Low DC resistance supports efficient power handling in impedance matching

Fixed Inductors Applications

• Antenna matching circuits
• RF filter networks
• Impedance matching applications

Fixed Inductors Procurement Notes

Verify the specific suffix B indicates the required tolerance level against project specifications. Confirm that the 0.7 nH value aligns with the target RF frequency requirements. Ensure the 1 A current rating meets the operational load conditions. Check for any RoHS compliance documentation if environmental regulations apply to the final assembly.

Fixed Inductors Selection Notes

Select this component when ultra-low inductance is critical for high-frequency signal integrity. The 0402 size is suitable for dense PCB layouts where space is limited. Consider the 1 A current rating for power handling needs. Verify that the ceramic core material suits the operating temperature environment up to 125°C.

Fixed Inductors Part Context

This part belongs to Abracon's AIMC-Q series of general-purpose RF inductors. It utilizes a multilayer ceramic technology distinct from wire-wound types. The series is optimized for SMD mounting on standard PCBs. It serves as a passive component in radio frequency signal paths.

Fixed Inductors Replacement Considerations

Cross-reference with other 0.7 nH 0402 multilayer inductors from manufacturers like Murata or TDK. Ensure equivalent DCR and current ratings are maintained. Verify mechanical footprint compatibility before substitution.
