AISC-Q0805-6N8K-T

$0.09

Description：FIXED IND 6.8NH 600MA 0.11OHM SM
Series：AISC-Q0805
Mfr：Abracon LLC
Package：Tape & Reel (TR)

SKU:aa39724407be Category: Fixed Inductors Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AISC-Q0805-6N8K-T is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is FIXED IND 6.8NH 600MA 0.11OHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for AISC-Q0805-6N8K-T

Description：FIXED IND 6.8NH 600MA 0.11OHM SM
Series：AISC-Q0805
Mfr：Abracon LLC
Package：Tape & Reel (TR)
Type：Wirewound
Material - Core：Ceramic
Inductance：6.8 nH
Tolerance：±10%
Current Rating (Amps)：600 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：110mOhm Max
Q @ Freq：50 @ 1GHz
Frequency - Self Resonant：5.5GHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：250 MHz
Mounting Type：Surface Mount
Package / Case：1008 (2520 Metric)
Supplier Device Package：805
Size / Dimension：0.090" L x 0.068" W (2.29mm x 1.73mm)
Height - Seated (Max)：0.090" (2.29mm)
Features：-

Fixed Inductors datasheet and documents for AISC-Q0805-6N8K-T

AISC-Q0805-6N8K-T

Fixed Inductors Overview

The AISC-Q0805-6N8K-T is a fixed inductor from Abracon LLC, designed for surface-mount applications. It features an unshielded wirewound construction with a ceramic core and offers a nominal inductance of 6.8 nH. The component has a maximum DC resistance of 110 mOhms and a current rating of 600 mA. Its self-resonant frequency reaches 5.5 GHz, supporting high-frequency operations. It operates within a temperature range of -40°C to +125°C and is housed in a 1008 (2520 Metric) package.

Fixed Inductors Feature Summary

High self-resonant frequency suitable for RF applications
Unshielded wirewound design with ceramic core
Compact surface-mount footprint

Fixed Inductors Applications

Impedance matching networks
Filtering for high-frequency communication circuits
Automotive electronics
Bluetooth devices
W-LAN systems

Fixed Inductors Procurement Notes

Verify the specific suffix 'K' indicates the required tolerance level during procurement. Confirm that the 1008 package dimensions align with your PCB land pattern requirements. Ensure the selected variant meets the necessary AEC-Q200 automotive reliability standards if intended for automotive use. Cross-reference the manufacturer's latest datasheet to confirm RoHS compliance status before finalizing orders.

Fixed Inductors Selection Notes

Select this component when a low inductance value near 7 nH is required for high-frequency signal integrity. Consider the 600 mA current rating against your circuit's peak load to prevent saturation. The unshielded nature may require layout considerations for EMI management. Evaluate the 5.5 GHz SRF to ensure it exceeds your operating frequency for effective filtering or matching performance.

Fixed Inductors Part Context

This part belongs to Abracon's AISC-Q series of multilayer RF ceramic chip inductors. These components are engineered for high reliability and tight tolerance ratings. The series utilizes a monolithic construction to provide improved direct current resistance and current-carrying characteristics compared to standard general-purpose inductors.
