AK3-170C-Y

AK3-170C-Y is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Littelfuse Inc.. Its product description is TVS DIODE 170VWM 260VC AXIAL. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for AK3-170C-Y

• Description：TVS DIODE 170VWM 260VC AXIAL
• Series：AK3-Y
• Mfr：Littelfuse Inc.
• Package：Bulk
• Type：Zener
• Bidirectional Channels：1
• Voltage - Reverse Standoff (Typ)：170V
• Voltage - Breakdown (Min)：179V
• Voltage - Clamping (Max) @ Ipp：260V
• Current - Peak Pulse (10/1000µs)：3000A (3kA) (8/20µs)
• Power - Peak Pulse：-
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：2400pF @ 10kHz
• Operating Temperature：-55°C ~ 125°C (TJ)
• Mounting Type：Through Hole
• Package / Case：Axial, Right Angle Bend (24.15mm Center)
• Supplier Device Package：Axial
• Unidirectional Channels：-
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for AK3-170C-Y
