AK3ADDF1-212.500T3

Oscillators Overview

The Abracon AK3ADDF1-212.500T3 is a surface-mount crystal oscillator operating at 212.5 MHz with LVDS output format. It features a frequency stability of ±25 ppm and operates within a temperature range of -40°C to +85°C. The device supports a supply voltage of 2.375V to 3.63V and draws a maximum current of 35 mA. Packaged in a compact 6-SMD, No Lead (3.2mm x 2.5mm) footprint, it complies with RoHS standards for environmental safety.

Oscillators Feature Summary

• Delivers low-jitter clock signals via differential LVDS outputs for high-speed data integrity
• Ensures stable frequency performance across industrial temperature extremes
• Supports flexible power supply integration within standard voltage ranges

Oscillators Applications

• High-speed serial communication interfaces requiring precise timing
• Data center infrastructure and server backplane applications
• Telecommunications equipment utilizing SERDES technology

Oscillators Procurement Notes

Verify the specific package dimensions and pin configuration against the official datasheet before PCB layout finalization. Confirm that the selected variant matches the required LVDS output format and frequency stability specifications for the target application environment. Ensure compliance with RoHS directives if applicable to the manufacturing region.

Oscillators Selection Notes

Select this component when differential signaling is required to minimize electromagnetic interference in dense circuit designs. Consider the ±25 ppm stability requirement against system jitter budgets. Evaluate the 3.2mm x 2.5mm footprint constraints against available board space and thermal management requirements for continuous operation.

Oscillators Part Context

This model belongs to the ClearClock AK3A series, designed for demanding digital applications. It utilizes MEMS or crystal technology to provide reliable clock generation. The series emphasizes small form factors and robust performance characteristics suitable for modern electronic systems requiring high-frequency precision.

Oscillators Replacement Considerations

Cross-reference part numbers from other manufacturers offering 212.5 MHz LVDS oscillators in 3225 packages. Verify electrical compatibility including supply voltage, current consumption, and phase noise specifications before substitution.
