ALAN-2204

$6.60

Description：PULSE XFMR 1CT:1CT 350UH
Series：ALAN-2204
Mfr：Abracon LLC
Package：Tube

SKU:a8ff0d2d8ff5 Category: Pulse Transformers Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PULSE XFMR 1CT:1CT 350UH
Series：ALAN-2204
Mfr：Abracon LLC
Package：Tube
Transformer Type：LAN 10/100 Base-T
Inductance：350µH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1CT:1CT
Mounting Type：Surface Mount
Size / Dimension：0.500" L x 0.346" W (12.70mm x 8.80mm)
Height - Seated (Max)：0.234" (5.95mm)
Operating Temperature：-40°C ~ 85°C
Grade：-
Qualification：-

Download product information

ALAN-2204

Overview

The ALAN-2204 is a LAN 10/100 Base-T pulse transformer module manufactured by Abracon LLC. It features a 350µH inductance and a 1CT:1CT turns ratio. Designed for surface mount installation, the component measures 12.70mm in length, 8.80mm in width, and has a maximum height of 5.95mm. It operates within a temperature range of -40°C to 85°C and supports VoIP/PoE+ capabilities.

Feature Summary

Supports 10/100Base-T Ethernet-LAN applications
Compatible with leading PHY IC manufacturers including Broadcom, Marvell, Micrel, and Microsemi
Provides PoE+ capabilities for power over Ethernet extensions

Applications

10/100 Base-T Ethernet network interfaces
VoIP (Voice over IP) systems
PoE+ enabled device connections

Procurement Notes

Verify that the specific part number matches the required specifications before procurement. Confirm compatibility with target PHY ICs such as Broadcom or Marvell. Ensure surface mount footprint dimensions align with PCB layout requirements. Check RoHS compliance status if environmental regulations apply to the final assembly.

Selection Notes

Select this component for designs requiring integrated LAN isolation with PoE+ support. The wide operating temperature range suits industrial environments. Verify inductance values match network interface controller requirements. Consider package size constraints when integrating into compact electronic devices.

Part Context

This component belongs to the ALAN series of LAN transformers from Abracon LLC. It is designed specifically for single-port Ethernet applications. The module integrates necessary magnetic components for signal coupling and isolation in high-speed data transmission networks.

Replacement Considerations

Public confirmed substitute part numbers include ALAN-102, ALAN-102-T, and ALAN-2201-T. These alternatives are listed as parameter equivalent options by the manufacturer.
