ALANS10002-7P11JT

Description：DUAL 10/100/1000BASE-T LAN XFMR
Series：ALANS10002
Mfr：Abracon LLC
Package：Tape & Reel (TR)

SKU:fbb87fb937c6 Category: Pulse Transformers Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：DUAL 10/100/1000BASE-T LAN XFMR
Series：ALANS10002
Mfr：Abracon LLC
Package：Tape & Reel (TR)
Transformer Type：LAN 10/100/1000 Base-T
Inductance：350µH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1CT:1CT Transmitter, 1CT:1CT Receiver
Mounting Type：Surface Mount
Size / Dimension：1.100" L x 0.297" W (27.94mm x 7.54mm)
Height - Seated (Max)：0.341" (8.66mm)
Operating Temperature：-40°C ~ 105°C
Grade：-
Qualification：-

Download product information

ALANS10002-7P11JT

Overview

The ALANS10002-7P11JT is a dual-port LAN transformer manufactured by Abracon LLC, designed for surface-mount technology (SMD/SMT) applications. It supports 10BASE-T, 100BASE-TX, and 1000BASE-T Ethernet standards. The component features an inductance of 350 uH and a primary resistance of 900 mOhms. It operates within a temperature range of -40°C to +105°C. The package dimensions are 27.8 mm in length, with a reel packaging format.
