ALF1T09

Product Detailed Parameters

• Description：RELAY GEN PURPOSE SPST 20A 9V
• Series：ALF
• Mfr：Panasonic Electric Works
• Package：Bulk
• Mounting Type：Through Hole
• Coil Voltage：9VDC
• Contact Form：SPST-NO (1 Form A)
• Contact Rating (Current)：20 A
• Switching Voltage：250VAC - Max
• Load - Max Switching：5000VA
• Coil Current：100 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：PC Pin, Quick Connect - 0.250" (6.3mm)
• Seal Rating：-
• Coil Insulation：-
• Must Operate Voltage：6.3 VDC
• Must Release Voltage：0.9 VDC
• Operating Temperature：-40°C ~ 60°C
• Contact Material：Silver Tin Oxide (AgSnO)
• Approval Agency：cURus, VDE
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：20 ms
• Release Time：15 ms
